Chicago to Milwaukee Driving Directions for your New or Used Utility Trailer Chicago to Milwaukee Trailers for Sale Driving Directions
New and Used Aluminum Utility TrailersCheap Aluminum Utility Trailers Wisconsin & Chicago

Call 414-762-7950 for Details.

Aluminum Utility Trailers

REG. $1,919.00
Sale! - $1,719.00
You Save $200.00 (10.4%)

Best Aluminum Utility Trailer Dealer in Wisconsin

Hanna RV carries and creates the best aluminum utility trailers in southern Wisconsin. We create custom lightweight flatbed trailers for cars and trucks and carry the best trailers from major brands like Triton. We build in sizes ranging from the standard 5x10 to custom dimensions of your choice. Call us at 414-762-7950 to discuss prices and options, or buy one of our standard models above. If you’d prefer the tried and true, browse our selection of steel utility trailers.

The main benefit to aluminum utility trailers is their low weight (in comparison to steel trailers). Customers with light duty tow vehicles benefit greatly from this. Let’s say a customer has a small SUV with a 1500 lb towing capacity. If they buy a Triton 5X10 aluminum utility trailer, they will be able to carry roughly 1100 lbs in the trailer without exceeding their towing capacity. This is because the Triton 5X10 aluminum trailer will weigh only 400 lbs whereas a steel 5x10 utility trailer will weigh roughly 1000 lbs. If a customer were to purchase the 5x10 steel trailers, they would only be able to load it with 500 lbs of cargo before meeting their maximum towing capacity and taxing the vehicle’s transmission.

Stop By and Check Out Our Selection of Aluminum Utility Trailers Today!

Hanna Trailer Supply offers high-quality aluminum utility trailers manufactured by Triton. Aluminum utility trailers are lightweight, and they offer a high level of corrosion resistance for long life and dependability.

Hanna Trailer Supply Aluminum Trailers, Woodsided And Other Utility Trailers

Why Aluminum?

Strength

  • Aluminum Alloy has about the same yield strength as steel

Maintenance

  • Aluminum doesn't require treatment or paint to be rust resistant
  • Treating and painting add to the expense of a steel trailer

Weight

  • Aluminum is lighter, offing a smoother ride and tow
  • The lower weight also translates into a higher payload capacity
  • Better gas mileage

Warranty / Resale

  • With routine cleaning and maintenance, aluminum trailers will look new for decades
  • Aluminum offers a lower risk investment than steel because the warranties are almost always longer and better than steel
  • Because of its performance and limited maintenance aluminum offers much higher resale value than steel

Common Anti-Aluminum Myth

Aluminum stresses and tears more easily than a steel trailer

If aluminum is such an inferior building material, why is its resale value consistently higher than steel? Why do you rarely find a steel trailer warranty that is longer than the warranty on an aluminum trailer? For that matter, why do people who own aluminum trailers keep them longer on average than people who own steel trailers?

If you want to be technical, steel is stronger than aluminum in some respects. It has a higher modulus of elasticity, for instance, which means more force must be applied to steel before it starts to bend. However, aluminum flexes three times as much as steel, which means that aluminum is more likely to spring back to its original shape after being stressed. Steel, though, will probably stay bent. Steel also fatigues at lower levels of stress than aluminum, and steel's rigidity makes it more vulnerable to cracking because of its brittleness.

You might also be interested to know that aluminum's lower modulus of elasticity works in its favor as a construction material for trailers. A lower elasticity modulus means that an all-aluminum trailer lessens impact shock loads while on the road, giving your machines a smoother ride and creating a smoother tow for your vehicle.

Aluminum: The Right Metal For The Job

The bottom line is that aluminum is a superior manufacturing material for trailers. While a steel trailer can do the job, an aluminum trailer almost always does it better. It lasts longer, too. You may save money initially, but after watching your trailer eventually wear down to rust and getting a replacement while your friends are still using an all-aluminum trailer, you'll know why so many people consider an all-aluminum trailer to have superior value.

Triton AUT Series Trailer Specifications Chart



Hanna Trailer Supply is a proud member of the North American Trailer Dealers Association. By maintaining our membership in this association of light and medium duty trailer dealers, the employees of Hanna Trailer Supply are able to keep up with the latest trends and education from industry professionals, and through NATDA benefits are able to pass along additional savings and value-added services to our customers. Click here to learn more about the NATDA.

Hanna Trailer Supply NATM Dealer Committed To Excellence

When you buy a Triton trailer, Parker Performance trailer, Forest River trailer, Liberty Industries trailer or any other brand name trailer, be sure to look for the NATM decal that signifies the trailer is National Association of Trailer Manufacturers' standards compliant for safety and performance. Trailer manufacturers must successfully complete the NATM Compliance Consultation in order to be allowed to use these decals on their trailers. The decal is the only way a trailer buying customer can be certain that a trailer complies with all Federal Motor Vehicle Safety Standards (FMVSS), as each of these manufacturers must complete their compliance consultation every two years. NATM is proud to uphold and support safety standards throughout the light and medium duty trailer industry. Hanna Trailer Supply offers only the best utility trailers, snowmobile trailers, enclosed trailers, aluminum utility trailers and many more trailers that carry the NATM compliant logo for our customers throughout southern Wisconsin and Northern Illinois. Click here for more consumer information provided by NATM and visit the Hanna Trailer Supply’s trailer sales lot located just south of Mitchell International Airport, on Howell Avenue in Milwaukee County.


AUT853
AUT864 AUT1064 AUT1064HD AUT1464 AUT1464-2 AUT1072 AUT1272 AUT1272-2 AUT1472 AUT1472-2 AUT1082 AUT1282 AUT1282-2 AUT1482 AUT1482-2 AUT1682
Specifications

BED LENGTH (IN.) 96 96 120 120 168 168 120 144 144 168 168 120 144 144 168 168 192
BED WIDTH (IN.) 53 64 64 64 64 64 72 72 72 72 72 82 82 82 82 82 82
BRAKE OPTIONS N/A N/A N/A N/A SURGE/ ELEC SURGE/ ELEC N/A N/A N/A N/A N/A SURGE/ ELEC SURGE/ ELEC SURGE/ ELEC SURGE/ ELEC STD. 1 ELEC STD. 1 ELEC
CARRYING CAPACITY W/O BRAKES (lbs.) 1850 1825 1800 2493 2235 2055 2475 2435 2170 2200 N/A 2315 2235 2115 2055 N/A N/A
CARRYING CAPACITY WITH BRAKES (lbs.) N/A N/A N/A 2998 2740 3460 2980 2940 4175 2705 5940 2820 2740 4120 2560 5880 5760
DECK HEIGHT N/A N/A N/A N/A N/A N/A 18.5 18.5 17.5 17.5 17.5 N/A N/A N/A N/A N/A N/A
GVWR W/O BRAKES (lbs.) 2200 2200 2200 2995 2995 2995 2995 2995 2995 2995 N/A 2995 2995 2995 2995 N/A N/A
GVWR WITH BRAKES (lbs.) N/A N/A N/A 3500 3500 4400 3500 3500 5000 3500 7000 3500 3500 5000 3500 7000 7000
HITCH HEIGHT (IN.) 18 17 17 18 14.5 14.5 15.5 15.5 14.5 14.5 14.5 14.5 14.5 14.5 14.5 14.5 14.5
LOADING STYLE REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP REAR RAMP
NO. OF AXLES 1 1 1 1 1 2 N/A N/A N/A N/A N/A 1 1 2 1 2 2
OPTIONAL TIRES ST205/75D14C 13" & R14" ALUM. RIMS ST175/80R13C SILVER or ALUM. ST205/75D14C SILVER or ALUM. ST175/80R13C SILVER or ALUM. ST205/75D14C SILVER or ALUM. ST205/75D14C ALUM ST205/75R14C ALUM ST205/75R14C ALUM ST205/75R14C SILVER ST205/75R14C ALUM. ST205/75R14C SILVER ST205/75R14C ALUM. ST205/75R14C SILVER ST205/75R14C ALUM. ST205/75R14C SILVER ST205/75R14C ALUM. ST205/75R14C SILVER ST205/75R14C ALUM. ST205/75R14C ALUM ST205/75R14C ALUM ST205/75R14C ALUM ST205/75R14C ALUM ST205/75R14C ALUM ST205/75R14C ALUM
OVERALL LENGTH (IN.) 142 142 165 165 226 226 160 193 199 223 223 174 198 198 240 229 257
OVERALL WIDTH (IN.) 75 86 86 86 80 86 86 93 93 93 93 93 102 102 102 102 102
PLYWOOD THICKNESS (in.) ALUMINUM DECK ALUMINUM DECK ALUMINUM DECK Aluminum Deck ALUMINUM DECK ALUMINUM DECK Aluminum Deck Aluminum Deck Aluminum Deck Aluminum Deck Aluminum Deck ALUMINUM DECK ALUMINUM DECK ALUMINUM DECK ALUMINUM DECK ALUMINUM DECK ALUMINUM DECK
RAMP STD. YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES YES
STANDARD TIRES ST175/80D13C ST175/80D13C ST175/80D13C ST205/75D14C ST205/75D14C ST205/75D14C ST205/75D14C ST205/75D14C ST205/75D14C ST205/75D14C ST205/75D14C ST205/75D14C ST205/75D14C ST205/75D14C ST205/75D14C ST205/75D14C ST205/75D14C
TILT BED NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO NO
TONGUE JACK N/A NO NO NO YES YES YES YES YES YES YES YES YES YES YES YES YES
TRAILER WEIGHT (lbs.) 350 375 400 502 760 940 520 560 825 795 1060 680 760 880 940 1120 1240
  Specifications and price will vary. Additional tire upgrades may be possible see your local dealer for details. Brake options will change the overall length of trailers. See your states DOT for details on brake laws in your state, it's the purchasers responsibility to adhere to brake laws. Recommended tongue weight is 7-10% of total GVWR. See your local dealer for pricing and availability.

Wisconsin's Dealer for Aluminum Utility Trailers

Hanna RV ships parts across the nation from Chicago to California and our store in Oak Creek just south of Milwaukee is visited each week by customers from across the Midwest, drawing the majority of our customers from the following cities and counties:

From the Milwaukee Metropolitan Area:

Milwaukee County: Milwaukee West Allis Wauwatosa Greenfield Franklin Oak Creek South Milwaukee
Cudahy Greendale Shorewood Whitefish Bay Glendale Brown Dear St. Francis

Waukesha County: Waukesha New Berlin Brookfield Menomonee Falls Muskego Oconomowoc Pewaukee
Hartford Lisbon Sussex Hartland Mukwonago Merton Delafield

Racine County: Racine Mount Pleasent Caledonia Burlington Norway Sturtevant

Kenosha County: Kenosha Pleasant Prairie Salem   Washington County: West Bend

Ozaukee County: Mequon


From the Madison Metropolitan Area:

 Dane County: Madison Sun Prairie Fitchburg Middleton Stoughton Oregon Waunakee

 Jefferson County: Watertown Whitewater   Dodge County   Walworth County


From the Green Bay Area:

Brown County: Green Bay De Pere   Winnebago County: Oshkosh Neenah

Outagamie County: Appleton   Sheboygan County: Sheboygan   Fond Du Lac County: Fond du Lac

Calumet County   Manitowoc County


From the Chicago Metropolitan Area:

Lake County: Waukegan Buffalo Grove Wheeling North Chicago Gurnee Mundelein Highland Park

McHenry County: Crystal Lake Algonquin   Kane County: Aurora Elgin

Cook County: Chicago   DuPage County Naperville   Kendall County: Joliet

Boone County: Belvidere   Winnebago County: Rockford   Stephenson County

Ogle County   DeKalb County   Will County

Prices are figured at cash or check. Credit card adds 2%.
