Ventline By Dexter BVD0449-A03 Smoke Wedge Shaped RV Roof Vent Cover For Standard Ventadomes
Ventline By Dexter BVD0449-A03 Smoke Wedge Shaped RV Roof Vent Cover For Standard Ventadomes
Attention Customers:
The items we have listed for pop up campers are the only items we have available. We are not able to special order any items at this time, and we are unable to provide technical assistance due to high order volume. Thank you for your understanding.
VideosReplaces the smoke-colored, wedge-shaped, polypropylene plastic cover on your Ventline Ventadome RV roof vent.
Features
- Replaces the wedge-shaped, polypropylene lid on Ventadome roof vents for motor homes and enclosed trailers
- Works with Ventline Ventadome roof vent models V2092, V2094, V2119, and V2128
- Measures: 14" x 14"
- Smoke color
- Made in the USA
Ventline RV Vents and Fans - BVD0449-A03
- Roof Vent
- Replacement Lid
- 14W x 14L Inch
- Tinted
- Ventline
- Continuous Hinge
BVD0449-A03 Replacement Dome Assembly for Ventline Ventadome Trailer Roof Vent - Smoke - Wedge Shape - Plastic
Replacement Instructions For Ventline Wedge Dome
1. Remove garnish trim, operator handle and screen frame to expose operator mounting screws.
2. Remove and save the two screws holding operator to the center bar. Remove operator from center bar and dome.
3. Remove dome retainer clip from the hinge by prying off with a small flat blade screwdriver or pliers.
4. Remove old dome and install new dome onto hinge.
5. Slide operator into slot in center bar and slide plastic slider clip onto dome slide bar. Install retainer clip onto hinge.
6. Replace the two screws through the operator assembly and into the center bar. Replace screen and operator handle. Check operation.
