Triton ATV128-2 Tandem Axle Aluminum 3 Place ATV / Utility Trailer with Stone Guard - 6.5' Wide x 12.5' Long (807867) (807867)

Cash / Check Price: $3449 + Tax.

Credit Card Add 2%.

The Triton ATV128-2 3 Place ATV Trailer is designed with quality materials to ensure you receive the best possible ATV or UTV trailer experience. With features like a straight ramp and full-length adjustable tie-down positions, you can be sure every detail has been crafted to get you to the trail without any hassles.

Trailer Specifications:

• Trailer Weight: 680 Lbs
• Carrying Capacity: 2315 Lbs
• GVWR: 2995 Lbs
• Brakes - Not Equipped
• Tandem Torsion Axles
• Overall Width: 79.75"
• Bed Width: 79"
• Overall Length: 202"
• Bed Length: 152"
• Hitch Height: 22"
• Deck Height: 25.5"
• All Aluminum Loading Ramp
• 1/2" Marine Grade Plywood Decking
• Tire Size: 20.5x10 LRE
• Adjustable Tie Down Brackets Full Length Of Side Channel

Dealer Installed Options:

• Front Rail Kit (08544)
• Aluminum Diamond Plate Stone Guard (11055)

Standard Features:

• All aluminum frame using custom integrated extrusions for light weight durability and rigidity.
• Strong, all welded aluminum ramp is standard with every ATV trailer.
• 79" wide deck is narrow enough to see around, yet wide enough for the wheel bases of large ATV's and rear loaded UTV's (use optional side saddle kit)
• Side rails 1/4" carriage bolt channels run the full deck length allowing #08660 tiedowns to be fully adjustable to properly secure all your loads.  (2 per machine, extas available)
• Aluminum loading ramp for rear and side loading of machines is a durable light weight ramp that stores in the rear of the trailer, and out of the way of your loads.
• Ramp Clamp system holds and secures the loading ramp under the deck and dampens the rattling effect of lesser designs.  Locks with provided padlock.
• Four cord rubber torsion axles for a smooth cushioned ride.
• E-Z Lube built in grease system for ease of maintenance and positive packing of both bearings and the hub.
• Molded wire harness for long life and durability; no splices to fail.
• Sealed LED Lights mounted in rubber grommets giving years of trouble free use.
• Safety chains with spring loaded clips.

Made In America

Manufactured In Hartford, Wisconsin
