Buyers 20344P HydraStar 3-Section Valve with Power Beyond

This product is a HydraStar 3-Section Valve with Power Beyond for your salt spreader. HydraStar® sectional valves consist of one to eight work sections. Options include power beyond, work/anti-cavitation ports, cable connection kits (B303035) for use with our RVC Series cables

Product Features and Specs

HydraStar® Standard Sectional Valve

• 20GPM Constant / 30GPM Momentary
• 2,250 PSI Factory Set Relief Valve / Manually adjustable to 3,200 PSI
• Inlet /Outlet Ports 3/4 Inch Straight Thread 1-1/16 Inch-12
• Work Ports 5/8 Inch Straight Thread 7/8 Inch-14
• 3-Way Detent for Plow Float
• 4-Way Double Acting Plow Angle, Set at 1,800 PSI Relief
• 4-Way Double Acting Dump Hoist, Set at 500 PSI for Power Down Relief
• Power Beyond for Spreader Valve

Specifications:

• Max Work Pressure: 4060PSI
• Flow Max: 21 GAL
• Temperature: 86°F-130°F
• Filtration of Oil: 25 Micron or Better
• Port Sizes: In/Out 3/4Inch Straight Thread (1-1/16-12)
• Work Ports 5/8 Inch Straight Thread (7/8-14)

Text Definitions:

• Power Beyond (permits use of neutral flow at system pressure); also permits field conversion from closed center to open center (tandem) operation
• 3 Way = Power Up, Gravity Down
• 4 Way = Power Up, Power Down
• 3 Position = Spool / Handle has 3 positions: Up/Neutral/Down
• Spring Centered = Spool returns to neutral when operator releases
• Detent = Valve Spool stays in position until changed by operator
• Weight: 32 lbs.
